65mm Bore Double Row Angular Contact Bearing
- SKU: -3213
Product Details
The structure of double row angular contact ball bearings is designed by arranging two single row angular contact bearings back-to-back in duplex (DB) to form a single bearing with a contact angle of 25°. These bearings are capable of accommodating radial loads, axial loads in either direction, and have a high capacity for moment loads
Product Specifications
| Manufacturer Product Code | 3213-BD-XL-TVH-C3 / FAG |
|---|---|
| inside dia id (mm) | 65 |
| outside dia od (mm) | 120 |
| width (w) (mm) | 38.1 |
| Model Ref | Name | UOI | Price (ex. VAT) | Stock | Qty |
|---|---|---|---|---|---|
| -3213 | Double Row Angular Contact Bearing 65mm ID x 120mm OD x 38.1mm Wide | 1 | £116.09 | In Stock | |
| -3313 | Double Row Angular Contact Bearing 65mm ID x 140mm OD x 58.7mm Wide | 1 | £243.90 | In Stock |
