60mm Bore Single Row Angular Contact Bearing
- SKU: -7312
- Single row angular contact bearings are designed with raceways that are displaced relative to each other along the bearing axis. This configuration allows them to manage simultaneous radial and thrust loads.
Product Details
Angular contact ball bearings are non-separable bearings with a defined contact angle in the radial direction relative to the straight line that runs through the point where each ball makes contact with the inner and outer rings. In addition to radial loads, angular contact ball bearings can accommodate single direction axial loads. Since an axial load is generated from a radial force, these bearings are generally used in pairs.Product Specifications
| inside dia id (mm) | 60 |
|---|
| outside dia od (mm) | 130 |
|---|
| width (w) (mm) | 31 |
|---|
