80mm bore Cylindrical roller bearings, single row
- SKU: -N316
- N‑type cylindrical roller bearings offer high radial load capacity with low friction. The inner ring has two ribs, allowing the roller and cage assembly to separate for easy mounting. Ideal as the floating bearing in fixed‑float arrangements where axial movement is required.
Product Details
NU type outer rings have two ribs. The outer ring, roller, and cage assembly can be separated from the inner ring. N-Type inner rings have two ribs. The inner ring, roller, and cage assembly can be separated from the outer ring. Unable to accommodate any axial loading. This is widely used as the floating side bearing in a fixed-float arrangement.Product Specifications
| Manufacturer Product Code | N316 -E-XL-TVP2-C3 |
|---|
| inside dia id (mm) | 80 |
|---|
| outside dia od (mm) | 170 |
|---|
| width (w) (mm) | 39 |
|---|
