Spherical Roller Bearings 100mm ID x 180mm OD x 46mm Wide

100mm Bore Spherical Roller Bearings

  • SKU: -22220

Product Details

The outer ring raceway of self-aligning ball bearings forms a spherical surface whose centre is common to the bearing centre. The inner ring of the bearing has two raceways. The balls, cage, and inner ring of these bearings are capable of shifting in order to compensate for a certain degree of misalignment with the outer rings. As a result, the bearing is able to align itself and compensate for shaft/housing finishing unevenness, bearing fitting error, and other sources of misalignment. Since axial load capacity is limited, self-aligning ball bearings are not suitable for applications with heavy axial loads.
In addition to spherical roller bearings with cylindrical bores, spherical roller bearings with tapered bores are also available. Bearings with tapered bores are specified by the suffix “K” at the end of the spherical roller bearing part number. The standard taper ratio is 1:12 for bearings with a “K” suffix.

Product Specifications

Manufacturer Product Code22220 -E1-XL-C3 | FAG
inside dia id (mm)100
outside dia od (mm)180
width (w) (mm)46
Model RefNameUOIPrice (ex. VAT)StockQty
-22220Spherical Roller Bearings 100mm ID x 180mm OD x 46mm Wide1 £323.89 In Stock
-22320Spherical Roller Bearings 100mm ID x 215mm OD x 73mm Wide1 £636.20 2-3 Days
-22220KSpherical Roller Bearings 100mm ID x 180mm OD x 43mm Wide1 £323.89 In Stock
-22320KSpherical Roller Bearings 100mm ID x 215mm OD x 73mm Wide1 £636.20 2-3 Days
-23120Spherical Roller Bearings 100mm ID x 165mm OD x 52mm Wide1 £374.11 2-3 Days
