Spherical Roller Bearings 190mm ID x 340mm OD x 92mm Wide

190mm Bore Spherical Roller Bearings

  • SKU: -22238

Product Details

The outer ring raceway of self-aligning ball bearings forms a spherical surface whose centre is common to the bearing centre. The inner ring of the bearing has two raceways. The balls, cage, and inner ring of these bearings are capable of shifting in order to compensate for a certain degree of misalignment with the outer rings. As a result, the bearing is able to align itself and compensate for shaft/housing finishing unevenness, bearing fitting error, and other sources of misalignment. Since axial load capacity is limited, self-aligning ball bearings are not suitable for applications with heavy axial loads.
In addition to spherical roller bearings with cylindrical bores, spherical roller bearings with tapered bores are also available. Bearings with tapered bores are specified by the suffix “K” at the end of the spherical roller bearing part number. The standard taper ratio is 1:12 for bearings with a “K” suffix.

Product Specifications

inside dia id (mm)190
outside dia od (mm)340
width (w) (mm)92
Model RefNameUOIPrice (ex. VAT)StockQty
-22238Spherical Roller Bearings 190mm ID x 340mm OD x 92mm Wide1 £2,106.69 2-3 Days
