Standard Metric Thrust Bearing. 60mm ID x 85 mm OD x 17 mm Wide

60mm Thrust Ball Bearing

  • SKU: -51112

Product Details

Thrust bearings are designed primarily to support axial loads at contact angles between 30° and 90°. Similar to radial bearings, thrust bearing designs may incorporate balls or rollers as rolling elements
the steel balls of single direction thrust ball bearings are arranged between a pair of washers (shaft washer and housing washer), and the normal contact angle is 90°. Axial loads can be supported in only one direction, and radial loads cannot be accommodated. These bearings are not suitable for high-speed operation.

Product Specifications

Manufacturer Product Code51112
inside dia id (mm)60
outside dia od (mm)85
width (w) (mm)17
Model RefNameUOIPrice (ex. VAT)StockQty
-51112Standard Metric Thrust Bearing. 60mm ID x 85 mm OD x 17 mm Wide1 £18.71 In Stock
-51212Standard Metric Thrust Bearing. 60mm ID x 95 mm OD x 26 mm Wide1 £30.25 In Stock
