Standard Metric Thrust Bearing. 80mm ID x 105 mm OD x 19 mm Wide

80mm Thrust Ball Bearing

  • SKU: -51116

Product Details

Thrust bearings are designed primarily to support axial loads at contact angles between 30° and 90°. Similar to radial bearings, thrust bearing designs may incorporate balls or rollers as rolling elements
the steel balls of single direction thrust ball bearings are arranged between a pair of washers (shaft washer and housing washer), and the normal contact angle is 90°. Axial loads can be supported in only one direction, and radial loads cannot be accommodated. These bearings are not suitable for high-speed operation.

Product Specifications

inside dia id (mm)80
outside dia od (mm)105
width (w) (mm)19
Model RefNameUOIPrice (ex. VAT)StockQty
-51116Standard Metric Thrust Bearing. 80mm ID x 105 mm OD x 19 mm Wide1 £28.23 In Stock
-51216Standard Metric Thrust Bearing. 80mm ID x 115 mm OD x 28 mm Wide1 £47.92 In Stock
